Ejector E-777

The ejector creates a vacuum in the system by virtue of water under pressure passing through its venture and opening the check valve. This spring opposed the check valve prevent water entering the vacuum gas pipe work on shut down of the system. The gas entering the ejector under vacuum via the check valve is vigorously mixed with the incoming water flow prior to injection in to the water to be treated.

Capacity : 0.5 Kg/Hr to 5 Kg/Hr

Maximum back pressure : 10 LBS

Water inlet connection : 1” PVC Union

Solution out let connection : 1” PVC Union

Vacuum gas connection : 10mm PVC union
