| Type | Ball Valve ( 3 Way Type) |
|---|---|
| Inlet connection | T - Port |
| Size | 3 / 4 “ |
| Body | CS |
| Ball | Monel |
| Sheat | PTFE |
| Shaft | Monel |
| End Connection | Screw End |
| Bore | Full |
| Make of Valve | AUDCO |
| * Actuator * | |||||
|---|---|---|---|---|---|
| Model | QT3 | ||||
| Rated Output Torque Kg m | 3 | ||||
| Operation Speed sec/90 | 18 | ||||
|
Switching Frequency Operation/hr
|
|||||
| Weight | 11 Kg | ||||
| Degree Of Protection | IP 65 / IP 67 | ||||
| Area Of Operation | Safe | ||||
| Motor Type | Non Blocking A.C. Motor | ||||
| Supply Std. | 220 V AC 50 Hz Single Phase | ||||
| Supply ptional | 110 V AC 50 Hz Single Phase | ||||
| Nominal Current | 150 m A | ||||
| Class Of Insulation | F | ||||
| Embient Temperature C | 45 | ||||
| Data Sheet of Motor | |
|---|---|
| Type | Non blocking A.C. Synchronous motor |
| Supply | 220 VAC 50/60 Hz 1 Phase |
| Insulation Class | B |
| Actuator / Panel mounted Positioner | PP 300 provided |
| Input for positioner from controller | 4 – 20 mA |
